Ozone and Oxygen concentrator 2 in 1 can be used in Water and Air for disinfection.

-



OZ-10G Specification

OZ-10G Specification

Ozone Output

Adjustable 4.0~10.0 g/h

Ozone concentration

>55 mg/L  at 5.0 L/min gas flow

Gas Flow

Adjustable 0.5 ~5.0L/min

Oxygen Purity

> 90 % +/-3%

Ozone generating method

German corona discharge

Input voltage

220 V AC  50 Hz (60 Hz optional)

Power input

400 W

Operating temperature

-10 deg C ~ +40 deg C

Storage temperature

-20 deg C ~ +70 deg C

Size  L x W x H

368 (L) X 342(W) X 572 (H) mm

Weight

19.5 with package
